Foot Bracket
Use this bracket to mount your cylinder to a parallel surface.

Foot Bracket Part Number Bore A B C D E F G  H J K L L07379 0016 5 / 16 1.00   .37   .25 .13   .37   .31   .25   .75 .06   .44 .12 L073790023 5 / 16 1.00   .37   .25 .13   .37   .31   .38   .75 .06   .44 .12 L073790024 7 / 16 1.38   .62   .31 .19   .50   .31   .38   .88 .07   .56 .12 L073790028 L077160028* 7 / 16 ,  9 / 16 1.38   .62   .38 .19   .50   .38   .44   .94  .09   .56 .12 L073790032 3 / 4 1.62   .75   .44 .19   .62   .41   .50 1.09 .10   .69 .19 L073790040 L077160040* 3 / 4 ,   7 / 8 ,   1 1 / 16 1.88 1.00   .56 .27   .75   .56   .63 1.38 .12   .81 .25 L073790048 L077160048* 1 1 / 4 ,   1 1 / 2 2.50 1.50   .75 .27   .94   .75   .75 1.75 .12 1.00 .38 L073790102 1 3 / 4 3.00 1.50   .87 .35 1.12   .91 1.03 2.16 .19 1.25 .50 L073790124 L077160124* 2 3.12 1.62 1.00 .34 1.12 1.00 1.38 2.50 .25 1.50 .62 L073790132 2 1 / 2 3.75 1.62 1.00 .35 1.44 1.25 1.51 3.00 .25 1.75 .75 L073790140 3 4.37 1.62 1.00 .35 1.75 1.25 1.64 3.14 .25 1.89 .89 * Stainless Steel for use with SRD/SRDM cylinders.
